DEK Grid-Lok module System, Universal PCB board support system, ASM Assembly

Sku # 16515: No Stock - But we have AVAILABLE a Universal Board Support, goto Sku # 16552 & DETAILS BELOW:

• Substrate PCB support for SMT processes
• Pin cap – electrically conductive silicone rubber compound
• Flexible system for automated board support along the entire SMT line: printers, placement machines, AOI, SPI, test systems.
• Stencil printers:

ASM, Ekra, Ersa, Juki, GKG, MPM, Speedline, Panasonic, Speedprint, Yamaha

===========================================================================

Sku # 16552 -> click here for more details

• Universal Board Support System:
• Can be used with: MPM, Dek, Speedline, ITW EAE, Ekra, Yamaha
• Controller and Operator Interface Sold Separately for each specific printer

& Add'tl Cost Varies depending on specific Mfgr & Model (Serial # needed)

• DEK Form-Flex Tooling
• DEK MK2 FormFlex Tooling
• 18 inches length of Board Support
• 44 Individual Pneumatic Tooling Pins per board support
• Total 6 Universal Magnetic Board Supports
• ESD protective tips have compliant flange to prevent damage to delicate components
• Self forming pneumatically driven pin matrix:
• Variations in the board layout is accommodated as the single pin pressure is small

enough to vary the height of the supporting pin without damaging the component

• Conforms to any given board
• Fully supports the underside of a populated board and stencil
• Form-Flex tooling consists of Pin Modules with pin up/down control and each module contains 44 pins in two rows
• High grade, polished stainless steel support pins for longevity
• Support pin locking mechanism is isolated from pin shafts to prevent lubricants from contaminating pins and eliminates sticking pins
• Each Form-Flex array is held magnetically to your manual tooling plate
• At product changeover the Form-Flex pins are positively retracted and reset

INCLUDES:

(1) Time Sequencer Assembly

(1) Manifold Assembly

(6) Tooling Modules

Additional Items Needed & Sold Separately:

(1) Controller

(1) Operator Interface

Will need: Mfgr, Model & Serial #

Not Included:

Tubing
