" BTU Pyramax™ 100A reflow ovens provide optimized lead-free processing for the ultimate productivity and efficiency. BTU’s exclusive closed-loop convection control provides precise heating, cooling and programmable heat transfer adding up to the lowest Cost of Ownership in the industry "

SKU 10158 : For pricing or questions please call or email us

• LOW Hours
• Mint-like Condition
• Yr: 03/2022
• High end Air reflow oven
• Horizontal Air flow
• 8 Zones Forced Air Convection - Forced Impingement Convection with side to side gas recirculation

Each zone utilizes BTU’s Porcupine II heating element: fast response time and high reliability

• Cooling zone equipped with 8 Cooling Fans
• Product clearance 2.0 in / 51 mm
• Rail Edge Conveyor
• Programmable (recipe controlled) width adjust
• Programmable multi-port lubricator
• Belt deviation detection
• Belt “Stopped” alarm & over torque protection provided via slip clutch
• Alarm and motion messaging via WINCON (trademark)
• Temperature control handled by Sixteen (16) PID control loops
• Redundant independent electronic over temperature protection: If an over-temperature occurs, power to the heaters is removed and audible/visual alarm activates
• Smart Tracker:
• allows the system to count products for a given recipe, detect product drop/lost and display a graphical view of the products
• In the event of a product drop, an alarm will sound
• manages oven SMEMA ready/busy logic for up and downstream
• Automatic shutdown sequencing
• Included on PC:

User Documentation

Maintenance Documentation

Troubleshooting and Repair Documentation

Hard Copy manual

• Total length 4.648 mm
• 8 top & 8 bottom zones
• Maximum temp. 350 Celsius
• Total Heated Length 00 inches / 254.0 cm
• Cooling length: 24 inches / 61.0 cm
• Exit Offload Area 20 inches / 50.8 cm
• Total System Width 60 inches / 152.4 cm
• Machine Weight 4,000 lbs. / 1,14 kg
• Power 480Y/277 94 Amp 3 Phase 50/60hz
• Max Temp 350 Celsius
• BTU's Innovative Software Solutions:
• Smart Power:

reduce peak power usage and lower your connected load, cutting energy costs

Benefit from automatic power optimization and achieve the fastest start-up and response times, all while keeping

total power limited. Save money and enhance productivity with smarter energy management.

• Energy Pilot:

Automatically reduces reflow oven operating costs

Takes advantage of idle time

• Recipe Pro by ECD:
• Automatic recipe generator:

Select Convection Rate and Throughput Preference

Select PCB Attributes

Select Solder Paste

• Reduces oven set-up time
• Exclusive convection rate algorithm
• Profile Guardian:
• Creates baseline for each recipe
• Profile Guardian limits and baseline data are stored with the recipe
• Designed to run continuously
• Integrated to software GUI
• Access level control
• Fully redundant controller
• Fully integrated with MES/factory communication
• Enables product traceabilty when used with a barcode reader (barcode reader not included)

BTU Pyramax 100A meets &/or exceeds:

ITW EAE Vitronics Soltec XPM2-820

ITW EAE Vitronics XPM3m 820

ITW EAE Vitronics Soltec Centurion CT820 Reflow Soldering Oven

JUKI RS-800II reflow oven

Manncorp CR8000 8-Zone SMT Reflow Oven

And far more superior to DDM Novastar 2000HT Conveyor Reflow Oven
