Horizon 03iX delivers the outstanding Horizon blend of performance and value. You get the benefits of revolutionary Instinctiv™ that is a user interface that features real-time machine advanced process reporting, on-board diagnostics, and features for rapid recovery. The new Optimised Printer Frame provides maximum mechanical and thermal stability along with the new ISCAN™ Intelligent Scalable Control Area Network. (info from DEK / ASM Assembly Systems Switzerland GmbH)

SKU 10744: For pricing or questions please call or email us

• Hawk Eye 750 Camera
• No DOA
• Functional Guarantee
• Operating System: Windows XP
• Under Stencil Cleaner
• Foiless board clamps
• Paste roll height monitor
• Solder paste dispenser
• Vacuum cup tooling
• Manual screen depth adjustment
• Maximum Board size: 20 inches
• Screen Frame Size: 736mm x 736mm (29x29")
• Screen Frame Thickness: 25mm - 38mm (1" - 1.5")
• Machine Alignment: > 2Cpk @ +/- 12.5um 6Sigma #
• Core Cycle Time: 12 secs
• LED Lighting, FOV 11.3mm x 8.7mm
• Camera Positioning: Rotary motors & encoders with micron resolution
• Squeegee pressure Mechanism: Software controlled, Motorized
• Stencil Positioning: Manual width screen depth adjuster
• Stencil Alignment: Motorized via actuators X, Y & Theta
• Width Adjustment: Programmable motorized rear rail
• Machine will come to you Fully Functional
• 45days to prepare/Test
